Owner’s Guide
6
ENGLISH
Turn the heating system off at the main electrical panel.
Loosen the bottom screw and remove the thermostat faceplate from its
wallplate. (The screw cannot be completely removed.)
Connect the thermostat to the load and to the power supply (see page 7).
Connect the floor sensor (see page 8).
If you wish to connect a remote control device, see page 8.
Install the wallplate to the electrical box using the provided screws.
Set the configuration switches on the back of the faceplate (see page 9).
Install the faceplate back on the wall plate and tighten the screw.
Apply power to the heating system.
Test the ground fault protection (see page 19).
Installing the thermostat
33-00221EFS_C.AUBE.book Page 6 Wednesday, January 20, 2021 11:17 AM
