Owner’s Guide
22
ENGLISH
Maximum load: 0.5 A / 24 VAC
Wire gauge: 14 to 22 AWG
Heating cycle length: 15 seconds
Display range: 0°C to 70.0°C (32°F to 158°F)
Ambient setpoint range (A/AF modes): 5.0°C to 30.0°C (40°F - 86°F)
Floor setpoint range (F mode): 5.0°C to 40.0°C (40°F - 104°F)
Floor limit range (AF mode): 5.0°C to 40.0°C (40°F - 104°F)
Resolution: 0.5°C (1°F)
Data protection: In the event of a power failure, most settings are saved. However the time
and Daylight Saving Time must be set if the power failure lasts more than 6 hours. The
thermostat will return to the mode that was active prior to the power failure.
Technical Specifications
