Figure 10. Parameter setup flow chart under (code 188).
6. Save and recall recipes
This controller can save up to 8 pieces of smoking recipe (programs). Each recipe file can have
up to 6 steps (C-1 to C-6). For convenience, we have pre-named these 8 pieces of recipe files as
B1 (beef), B2, C1 (chicken), C2, F1 (fish), F2, P1 (pork), and P2. These recipe files are all the
same except their names, so you can store your special recipe to any of them. These recipes
can be stored in the memory of the controller even when it is powered off. You can overwrite the
exist recipe with a new one.
6.1 Save a recipe.
After a program has been entered, the user can save this current program as a recipe for future
use. Under the normal operating mode, press and hold SET key for 3 seconds until the
Parameter Window displays “LoCK”. Release the SET. The display will show “0”. Use “+” and “-”
keys to adjust the display to 2 and press SET. The display will show “SAVE” for a second and
then the value “End”. If press SET key now, you will exit this mode without overwriting any
existing programs. Use “+” or “-” key to select the name of recipe to which you want to store the
program. If you press “+” (or “-” key) repeatedly, you will see “End”, “b1”, “b2”, “C1”, “C2”, “F1”,
“F2”, “P1”, “P2” one by one. Press the SET key again to store your current program under the
selected recipe name. This process will overwrite the current recipe data to the saved recipe
data. Figure 11 shows the flow chart of how to save a recipe.
To Next Page
