REMARK
Detaching the upper input board (containing terminal block and RS-232 sockets)
may facilitate the installation. Make sure it is well fastened again afterwards.
Step 4:
Once the Ethernet connection PCB is correctly installed, the supplied ethernet connection
cable shall be plugged to the RJ45 connection socket in the inner side of the ethernet
connection board.
