AUDAC CS55 User Manual

4
44
4
Specifications
Nominal Power 10 Watt
SPL (1W/1m) 93 dB
SPL (20W/1m) 100.8 dB
Impedance 8 Ohm
Line transformer impedance 1600 Ohm/6W
3300 Ohm/3W
6600 Ohm/1,5W
Frequency Response -3dB Fo - 14kHz
Frequency Response -10 dB Fo - 16kHz
Dimensions (Diameter x Depth) 205x70 mm
Cut-out Diameter 165 mm
Weight 0,70 Kg
Mounting 4 Screws with clamp
Color White RAL9010

AUDAC CS55 Specifications

General

Brand	AUDAC
Model	CS55
Category	Speakers
Language	English
