AUDAC MERO2 User Manual

8
Additional Information
Technical specifications
RMS Power 10 Watt
Max. Power 20 Watt
Nominal impedance 8 Ohm
Sensitivity (1W / 1m) 83 dB
Sound pressure (Max W / 1m) 93 dB
Frequency response (±3 dB) 120 Hz - 20 kHz
Drivers 2” Aluminium full range
Connectors Gold plated spring clamps
Mounting 2-Screw quick-fixing mechanism
Construction High-Quality ABS
Front finish White Thin edge grill (RAL9003)
(1 mm width x 3.2 mm height edge)
Dimensions 146 x 98 x 70 mm
Cut-out measurement 128 x 80 mm
Built-in depth 70 mm
Weight 0.355 Kg
Packaging Carton box
Shipping weight & Volume 0.5 Kg - 0,0026 Cbm
Accessories included Cut-out template
Instruction manual

AUDAC MERO2 Specifications

Power and Impedance

RMS power	10 Watt
max power	20 Watt
nominal impedance	8 Ohm

Audio Specifications

sensitivity	83 dB
sound pressure	93 dB
frequency response	120 Hz - 20 kHz

Weight and Dimensions

weight	0.355 Kg
dimensions	146 x 98 x 70 mm
built-in depth	70 mm
