Audio Note COBRA - Technical Specifications

INPUT IMPEDANCE
100K ohm, line level
INPUT SENSITIVITY
300mV for full output
MAXIMUM OUTPUT
27 watts RMS per channel into 8 Ohm
loads
CHANNEL BALANCE
+/- 0.3dB
VALVE COMPLEMENT
2 x EL34
2 x 5670
2 x 6AU6
FUSE RATING
110 / 120V supply:
1 x 3.15A anti-surge
220 / 240V supply:
1 x 1.6mA anti-surge
UNIT WEIGHT
13.6 KG
SHIPPING WEIGHT
(ORIGINAL PACKAGING)
15 KG
UNIT DIMENSIONS
180mm (h) x 340mm (w) x 450mm (d)
SHIPPING DIMENSIONS
(ORIGINAL PACKAGING)
260mm (h) x 420mm (w) x 540mm (d)
SUPPORTED SAMPLING
FREQUENCIES
(DIGITAL INPUTS)
USB: up to 16-bit/48kHz
Optical TOSLINK: up to 24-bit/96kHz
COAX: up to 24-bit/176kHz
MAX. POWER CONSUMPTION
175 Watts
NOTE
Due to Audio Note (UK)’s ongoing
research and development program,
specifications are subject to change
without notice.
TECHNICAL SPECIFICATIONS
