Audio Technica ATH-G1WL User Manual

9
Using the product
Button operation
Microphone monitor button
You can check the sound of your voice during use by pressing the microphone monitor button. Each time the
microphone monitor button is pressed, it switches between ON and OFF.
Volume/surround sound selector switch
Use to adjust the volume and turn virtual surround playback on and off..
Slide toward + Increases the volume by 1 level.*
1
Slide toward - Decreases the volume by 1 level.*
1
Press Each time you press the volume/surround sound selector switch, you switch ON/OFF.*
2
*1 A beep is heard when the volume is at the maximum or minimum level.
*2 A confirmation tone sounds each time you switch ON/OFF.
Mute switch
To mute the microphone, switch the mute switch to ON.
Swivel mechanism
You can fold the housing so that it lies flat.
• The swivel mechanism cannot rotate more than 90 degrees. Do not apply excessive force.
Joint

Audio Technica ATH-G1WL Specifications

General

Headset type	Monaural
Product type	Headset
Product color	Black
Wearing style	Head-band
Recommended usage	Gaming
Frequency band	2.4 GHz
3.5 mm connector	Yes
USB connectivity	-
Connectivity technology	Wireless
Impedance	45 Ω
Driver unit	45 mm
Headphone frequency	5 - 40000 Hz
Headphone sensitivity	101 dB
Microphone type	Built-in
Microphone frequency	30 - 20000 Hz
Number of microphones	1
Microphone sensitivity	-43 dB
Battery voltage	3.8 V
Continuous audio playback time	15 h
Operating temperature (T-T)	5 - 40 °C
Package depth	222 mm
Package width	228 mm
Package weight	670 g

Weight and Dimensions

Weight	297 g
