Audio Technica ATH-G1WL User Manual

8
Using the product
Power supply ON/OFF
Wearing the product
Power
supply
Power switch operation Indicator lamp
ON
Lights in blue, then flashes in blue *
1
*
2
OFF Lights in blue, then turns off *
2
*1 It may take several seconds for the indicator lamp to light.
*2 For details, refer to “Indicator lamp display” (p. 11).
• Lower the volume of the Windows PC/Mac, and then connect the product and adjust to the desired volume.
1. Attach the detachable microphone to the product.
• Make sure that the detachable microphone is attached securely.
2. Put the side of the product marked “L” (LEFT) onto the left ear and
the side marked “R” (RIGHT) onto the right ear, slide the slider up
and down so that the earpads cover the ears, and then adjust the
headband.
3. Adjust the microphone near the corner of your mouth.

Audio Technica ATH-G1WL Specifications

General

Headset type	Monaural
Product type	Headset
Product color	Black
Wearing style	Head-band
Recommended usage	Gaming
Frequency band	2.4 GHz
3.5 mm connector	Yes
USB connectivity	-
Connectivity technology	Wireless
Impedance	45 Ω
Driver unit	45 mm
Headphone frequency	5 - 40000 Hz
Headphone sensitivity	101 dB
Microphone type	Built-in
Microphone frequency	30 - 20000 Hz
Number of microphones	1
Microphone sensitivity	-43 dB
Battery voltage	3.8 V
Continuous audio playback time	15 h
Operating temperature (T-T)	5 - 40 °C
Package depth	222 mm
Package width	228 mm
Package weight	670 g

Weight and Dimensions

Weight	297 g
