AudioCodes Mediant 1000B Quick Setup Guide

3 | Page
2
CRMX
CRMX module, providing
 RS-232 serial interface port (flat connector).
 Dry-contact relay connector for interfacing with a third-party, external alarm
system (separate orderable item).
 Reset pinhole button for resetting the device or restoring it to factory defaults
(press and hold down the button for at least 12 seconds, but no more than 25
seconds).
 Gigabit Ethernet LAN interface ports (RJ-45) for connecting IP phones,
computers, or switches. The ports support 1+1 Ethernet port redundancy
(active-standby), half- and full-duplex modes, auto-negotiation, and straight-
through or crossover cable detection. Each port has a status LED:
Green On
Ethernet link established.
Green Flashing
Data is being received or transmitted.
Off
No Ethernet link.
The WAN / STATUS LED indicates the following:
Red On
Reset button has been pressed.
Red Flashing

Under-voltage condition on CRMX module.
 Booting up phase (U-boot) of the operating system
kernel has completed successfully.
Note: When the device is ordered with dry-contact relay
interfaces, the LED label is STATUS; otherwise, the label
is WAN (despite no WAN interfaces).
Green On
Dry contact relay alarm: No Alarm (Dry Contact I Closed
and II Open).
Orange On
Dry contact relay alarm: Minor Alarm (Dry Contact I and
II Open).
Red On
Dry contact relay alarm:
 Major Alarm (Dry Contact I and II Closed).
 Critical Alarm (Dry Contact I Open and II Closed).
3
SWX
LAN Extension (SWX) module, providing four additional Gigabit Ethernet LAN port
interfaces.
Note: The SWX module is a separate orderable item.
4
Power 1
Secondary Power Supply module, providing load sharing with and power
redundancy in case of failure in primary Power Supply module.
Note: The secondary Power Supply module is a separate orderable item.
5
Power 2
Primary Power Supply module with a status LED:
Green On
AC power is received by device.
Off
No power.
6
-
Fan Tray module and a schematic on its front panel showing the chassis' slot
numbers.

AudioCodes Mediant 1000B Specifications

General

Brand	AudioCodes
Model	Mediant 1000B
Category	Gateway
Language	English
