Version 5.6 29 November 2008
Installation Manual 3. Configuring the Device
3 Configuring the Device
This section provides basic device configuration. This is performed mainly by using the
device's embedded Web server (Web interface).
3.1 Assigning an IP Address
The device is supplied with application software (cmp file) residing on its flash memory.
This software is set to factory default settings such as MAC and IP address, as listed in the
table below. However, you may need to change the device's default IP address to
correspond with your network environment.
Table 3-1: Default IP Addresses
Parameter Default Value
IP Address
FXS and FXS / FXO devices: 10.1.10.10
FXO device: 10.1.10.11
Note: FXO interfaces are applicable only to MP-11x series
devices.
Subnet Mask
255.255.0.0
Default Gateway IP Address
0.0.0.0
To assign an IP address to the device, use one of the following methods:
Device's HTTP-based embedded Web server accessed using a Web browser (refer to
'Assigning an IP Address Using HTTP' on page 30).
BootP (refer to 'Assigning an IP Address Using BootP' on page 31).
Voice Me
nu using a standard touch-tone telephone connected to one of the FXS
analog ports (refer to ‘Assigning an IP Address Using the Voice Menu Guidance’ on
page 32). Thi
s method doesn’t apply to FXO modules.
Embedded Command Line Interface (CLI) accessed using RS-232 or Telnet (refer to
'Assigning an IP Address Using the CLI' on page 35).
Dynamic Host Control Protocol (DHCP) (refer to the User's Manual).
Note: You can restore the device's networking parameters to their factory default
values using the device's hardware Reset button (refer to 'Restoring Factory
Default Settings' on page 42).
Tip:
Record and retain the IP address and subnet mask you assign the device. If
the Web interface is unavailable (for example, if you’ve lost your IP address),
use the BootP/TFTP utility to access the device (refer to the Product
Reference Manual).
