Deployment Guide 2. RXV100 Components
Version N/A 11 RXV100
2.1 RXV100Hub
The core of the RXV100 is the RXV100Hub, shown in the figure below.
Use the table as reference.
Table 2-2: RXV100Hub
Legend Description
1 RGBW LED Lens
2 Microphone (four)
3 10.1” Display
4 Speaker Column
5 Motion Sensor
6 RGBW LED Lens
7 3.5 mm audio jack
8 Power / Reset
The RXV100Hub is based on the Lenovo ThinkSmart Hub certified for Microsoft Teams. Built
on the MTR platform that enterprise employees already know and use, the RXV100Hub lets
participants communicate and collaborate via video, voice or content sharing in real time. The
device’s rotatable 10.1-inch touchscreen display makes it easy for members of the group to
share and control the meeting.
