8
CORRECT
FROM THE CENTRE TO THE EDGE
INCORRECT
DO NOT STORE NEAR HEAT
4. Cleaning a disc
z Should the disc become soiled, wipe off dust, dirt and fingerprints with a soft cloth.
z The disc should be cleaned from the center to the edge.
z Never use benzene, thinners, record cleaner fluid or anti-static spray.
z Be sure to close the CD door, so the lens is not contaminated by dust.
z Do not touch the lens.
SPECIFICATIONS
GENERAL
Power Requirement AC 230V ~ 50Hz
DC 12V UM-2 /ĀCāSIZE x 8 PCS(Not included)
Power consumption 21 Watts
Off mode power: < 0.5 Watts
Weight Approx. 2.5 kg
Dimension Approx. 44.7 (L) x24.3 (W) x 17.3 (H) cm
Operation Temperature +5 °C - + 35 °C
RECEIVER SECTION
Receiving Bands AM / FM
Tuning Range AM: 526 - 1606 KHz
FM: 87.5 - 108 MHz
Antenna: FM rod antenna, AM built-in ferrite bar
COMPACT DISC SECTION
Optical Pickup 3-Beam Laser
Frequency Response 100Hz – 16 KHz
AUDIO SECTION
Power Output 2.5 W x 2(RMS)
Headphone Impedance 32 Ohms
Note: Specifications are subject to change for continuous improvement without prior notice.
