1. Speaker Connection
2. Battery +12V Input
3. Remote Turn-on Input
4. Ground
1. Remote Bass Level Control
2. RCA Input Jacks
3. Bridge in
2
1 5 6
21 3 4
APSM-1300
4. Bridge out
5. Power Indicator LED
6. Protection Circuit Indicator LED
3 4
