Audiopipe APSM-1150 - Page 9

English
76 8
21 5
9 10
3 4
1. Front GAIN Control
2. Front Filter Select Switch
3. Front HPF Control
4. Front Bass boost Level
5. Front LPF Control
6.
7.
8.
9.
10.
Rear GAIN Control
Rear Filter Select Switch
Rear HPF Control
Rear Bass boost Level
Rear LPF Control
