FRONT PANEL RELEASE
The front panel release button (4) releases the mechanism that holds the front panel to the chassis.
Detaching the Front Panel
To detach the front panel, perform the following steps:
1. Press the power button (1) to turn the unit off.
2. Press the front panel release button to flip the panel down.
3. Grasp the right side to release the front panel and then pull it at an
angle to remove the right side from the chassis.
4. Store the front panel it in the supplied carrying case to protect it from dirt
and damage and take it with you to prevent theft.
Re-attaching the Front Panel
Before re-attaching the front panel, make sure the electrical terminals on the back of the panel are free of dust and dirt, as debris could cause
intermittent operation or other malfunctions.
To re-attach the front panel:
1. With the panel laying flat (in the “open” position), insert the left side of the panel in place until correctly engaged.
2. Gently press the right side of the panel until the mechanism locks it into place.
3. Lift upward to close the panel.
REMOTE CONTROL
The remote control will allow you to control the advanced functions of the VME 8013.
Operating Range
The remote control sensor (19) is located near the bottom of the front panel, left of the LCD
screen. The remote control can operate within a distance of 3~5m.
Replacing the Battery
When the range of operation of the remote control becomes short or stops functioning,replace the battery with a new lithium battery.
Be sure to observe the proper polarity, as indicated below.
6
Subject to technical changes
