Audison LRx 4.5 Service Manual

Part 1G page 1 of 7
LRx SERIES COMPONENTS PIN-OUT: Leaded components
Rev. A
Case TO220
N channel mosfet transistor
Type Product name Marking code
PIN OUT
G: Gate
D: Drain
S: Source
(1) (2)
(3)
G D S
G D S
Switching power
Switching power
IPP80N06S2-09
IPP80N06S2-05
2N0609
2N0605
G D S
Switching power
IRFB33N15D
FB33N15D
G D S
Switching power
IRFB52N15D
FB52N15D
G D S
Switching power
IRFB61N15D
FB61N15D
G D S
Switching power
IRFB260N
FB260N
Ref.
A K A
Common Cathode
FFPF10U20DN
A
K
Power rectifier
BYT79-500
BYT79-500
S
G
D
N ch.
(2)(3)(1)
A: Anode
K: Cathode
Type Product name Marking code
PIN OUT
Ref.
(1) (2)
Single ultra fast power diodes
K A
Dual ultra fast power diodes
Type Product name Marking code
PIN OUT
F10U20DN
K A K
Common Anode
FFPF10U20DP
F10U20DP
(1) (2)
(3)
Ref.
Case TO220F (to insulate with thermo-conductive grease)
A
A
K
K
K
A
C. Cathode
C. Anode
(2)(3)(1)
A: Anode
K: Cathode
(2)(1)
NPN bipolar transistor
Ty
pe
Product name Marking code
PIN OUT
(1) (2)
(3)
B C E
B C E
Audio driver
Darlington
2SD2400A
BDW93C
-
BDW93
Ref
.
(2)(3)(1)
PNP bipolar transistor
Type Product name Marking code
PIN OUT
(1) (2)
(3)
B C E
B C E
Audio driver
Darlington
2SB1569A
BDW94C
-
BDW94
Ref.
NPN
PNP
E
B
C
E
B
C
A
K
Power rectifier
MUR1540
MUR1540
