LRx 4.5 ASSEMBLED AMPLIFIER PARTS LIST
Rev. B
Part 2A page 1 of 2
REF. NO PART NO DESCRIPTION Q.TY
1 10020510 LRx SLIDE SWITCH KNOB 9
2 10020520 LRx POTENTIOMETER KNOB Lg 2
3 10020530 LRx POTENTIOMETER KNOB Sh 2
4 10081113 LRx Lg GRAY CONTROL PANEL 1
5 10081123 LRx GRAY PWR-FUSE PANEL PAINTED 1
6 10081130 LRx Lg-IN ENDS SUPPORT 1
7 10081160 LRx4.5 PWR ENDS SUPPORT (ATP 4-6W) WITH SILKSCREEN 1
8 10081173 LRx SATIN GRAY TRANSP Lg COVER 1
9 10081193 LRx GRAY FRONT-END SHIELD 1
10 10081213 LRx GRAY CABLE-END SHIELD 1
11 10081241 LRx TRANSP AUDISON LOGO 1
12 10221173 LRx4.5 GRAY STICKER FOR CONTROL PANEL 1
13 10221220 LRx4.5 / LRx4.1k STICKER FOR Lg-IN ENDS SUPPORT 1
14 12112910 M5x18 SCREW TB EI (4) + WASHERS NICKEL PLATED 2
15 12130200 2.9x13 SCREW (AFsp TC C ZN) 4
16 12500560 LRx TO220 SPRING (10mm) 10
17 12500570 LRx TO3P SPRING (15mm) 12
18 14403060 LRx 218mm BOTTOM (LRx 4.5) 1
19 15120100 LRx ASSEMBLED DISPLAY PCB - CABLE 210mm 1
20 15230510 LRx RCA INPUT 1
21 15270520 FUSEHOLDER FOR 2W-TBF 1
22 15289846 FUSE 40A (SFA TYPE) 2
23 23824063 LRx 243mm GRAY HEAT-SINK (LRx4.5) 1
24 10081181 LRx Sh COVER - PAINTED 1
25 32101210 3x10 SCREW (HILO TBOTT. EI 2 CR) 4
26 32101220 3x10 SCREW (UNI 9707 HILO TC C ZN) 2
27 32130501 2.9x4.5 SCREW (AFsp TC C ZN) 4
28 32150031 3.2x7.0 SCREW (AFsp TFR C ZN) 10
29 32150110 3.5x13 SCREW (AF TC C ZB) 4
30 33540103 LRx Lg LEFT GRAY ZAMAK TERMINAL 1
31 33540113 LRx Lg RIGHT GRAY ZAMAK TERMINAL 1
32 33540123 LRx Sh LEFT GRAY ZAMAK TERMINAL 1
33 33540133 LRx Sh RIGHT GRAY ZAMAK TERMINAL 1
34 34125043 LRx 4.5 GRAY LABEL 1
35 34150020 242x25mm INSULATION Al. STRIP 2
36 34561020 LRx 243mm STRIP - SILVER (LRx4.5) 1
37 36726310 LRx4.5-MB C.S.ASS. (LRx4.5 MAIN BOARD) 1
38 36726630 LRx4.5-C.1 C.S.ASS. (LRx4.5 CONTROLS) 1
LRx 4.5 PACKAGE PARTS LIST
1 11116930 LRx4.5 CARTON BOX 1
2 11501540 LRx INNER CARTON 2
3 10039800 HIGH DENSITY POLIETHILENE BAG 27x56 1
4 10040400 HIGH DENSITY POLIETHILENE BAG 20x30 1
4 10120900 AUDISON WARRANTY rev. B 1
4 10125110 RAEE/WEE INFORMATION 1
4 10125240 LRx 4.5 / LRx 4.1k OWNER’S MANUAL 1
4 10125260 LRx FIXING TEMPLATE 1
4 10125270 LRx 4.5 CONFIGURATION TEMPLATE 1
4 90200020 AW STICKER S - AUDISON Transfer Sticker 19x7 1
5 10045000 10x16 AUDISON BAG 1
5 10081221 LRx PLAST SNAP-IN CABLE FIX ACCESSORY KIT 1
5 12150520 3.9x25 SCREW (AFcp TC C ZN) 4
5 12600610 90mm PH2 INSERT 1
5 15240030 LRx FASTON ACCESSORY KIT 1
5 30024510 AUDISON MULTISPANNER 1
6 15230520 LRx IN-HI INPUT (ECI-HI) 1
7 10040400 HIGH DENSITY POLIETHILENE BAG 20x30 1
7 10081203 LRx GRAY REAR-END SHIELD 1
7 10081170 LRx Lg COVER - PAINTED 1
REF. NO PART NO DESCRIPTION Q.TY
Rev. B
