POWER SUPPLY PANEL
1 - Open the transparent cover by pushing the two teeth in
its lowest corners to the direction indicated by the arrows.
4 - Close the transparent cover.
3 - Check the value of the new fuse to assemble, then fix it by
gradually and alternately fastening the two screws. This will
avoid voltage drops along the line and will make the device
perfect functioning easier.
2 - Remove the screws which fasten the fuse to eliminate
pieces of the broken one; prevent them from going into the
device.
FUSE REPLACEMENT
18
