Audison LRx Series User Manual

CENTER
FRONT RIGHT
REAR RIGHT
FRONT LEFT
REAR LEFT
SUB
SUB FRONT
CENTER REAR
A/V PROC
34 35
Manuale d’uso
The Universal Sound
LRx 3.1MT
LRx 5.1MT
I LRx 5.1MT: A / V 5.1 System (Front + Rear + Center + Sub)
Sezione d’alimentazione
Tensione
Assorbimento minimo
Assorbimento da spento
Assorbimento @ 14.4 VDC
(Potenza musicale MAX)
Tensione di Remote IN
Tensione di Remote OUT
Fusibile interno (AFS)
Sezione d’amplificazione
Distorsione A,B,Centre Ch - THD (1 kHz @ 4 Ω)
Distorsione SUB Ch - THD (100 Hz @ 4 Ω)
Banda passante A,B,Centre Ch (-3 dB)
Banda passante SUB Ch (-3 dB)
Rapporto S/N A,B,Centre Ch (pesato A @ 1 V)
Rapporto S/N SUB Ch (pesato A @ 1 V)
Fattore di smorzamento A,B,Centre Ch (1 kHz @ 4 Ω)
Fattore di smorzamento SUB Ch (100 Hz @ 4 Ω)
Sensibilità d’ingresso (PRE IN)
Sensibilità d’ingresso (Speaker IN)
Impedenza d’ingresso (PRE IN)
Impedenza d’ingresso (Speaker IN)
Impedenza di carico (MIN)
• 4 Ch (A + Centre + SUB Ch)
• 6 Ch (A + B + Centre + SUB Ch)
Potenza d’uscita Nominale (RMS) PN @ 12 VDC;
A,B,Centre Ch THD 0.3%; SUB Ch THD 1%
Potenza d’uscita (RMS) @ 14.4 VDC; THD 1%
• 4 Ch 3 Ch x 4 Ω + 1 x 4 Ω
• 4 Ch 3 Ch x 4 Ω + 1 x 2 Ω
• 6 Ch 5 Ch x 4 Ω + 1 x 4 Ω
• 6 Ch 5 Ch x 4 Ω + 1 x 2 Ω
Sezione Ingressi / Uscite / Filtri
IN A Ch
IN B Ch
IN Centre Ch
IN SUB Ch
OUT (Bypass)
A Ch Filter (24 dB/Oct.)
B Ch Filter (24 dB/Oct.)
Centre Ch Filter (Mono 24 dB/Oct.)
Subsonic
Controllo Remoto del Volume del Sub
Dimensioni
B x L x H mm
Peso kg
11÷15 VDC
3.6 A
0.02 mA
87 A
7÷15 VDC (1 mA)
12 VDC (50 mA)
100 A
0.03 %
0.5%
4÷58k Hz
4÷700 Hz
103 dB
85 dB
190
90
0.3÷5 V
1.4÷24 V
15 kΩ
5 kΩ
5x4 Ω + 1x2 Ω
85 W x 5 + 360 W
100 W x 5 + 460 W
100 W x 5 + 780 W
PRE / Speaker
PRE / Speaker
PRE / Speaker
PRE / Speaker
PRE
Bypass / Hi-pass 30 Hz
Bypass / Hi-pass 30 Hz
Bypass / Hi-pass 30 Hz
OFF/20/30 Hz @ 24 dB/Oct.
+5 ÷ -5 dB
198 x 588 x 56
6.0
11÷15 VDC
2.2 A
0.02 mA
72 A
7÷15 VDC (1 mA)
12 VDC (50 mA)
80 A
0.03%
0.5%
4÷58k Hz
4÷700 Hz
105 dB
85 dB
200
90
0.3÷5 V
1.4÷24 V
15 kΩ
5 kΩ
3x4 Ω + 1x2 Ω
95 W x 3 + 420 W
100 W x 3 + 460 W
100 W x 3 + 800 W
PRE / Speaker
PRE / Speaker
PRE / Speaker
PRE / Speaker
Bypass / Hi-pass 30 Hz
Bypass / Hi-pass 30 Hz
OFF/20/30 Hz @ 24 dB/Oct.
+5 ÷ -5 dB
198 x 488 x 56
5.0
Caratteristiche tecniche
Standard di misura Audison
