Perimetro esterno
External Outline
Perimetro per il montaggio semi-incassato
Semi-Projecting Outline
Input Cable
Hole Area
Perimetro per il montaggio a filo del pannello
Non-Projecting Outline
Input Cable
Hole Area
I
CONNECTION Audison Y BLOCK
43
35
Push
to click
MAX ø6,5 mm
1
2
63
The Universal Sound
62
LRx 3.1MT
LRx 5.1MT
Owner’s manual
A template is supplied to help you pre-plan the mounting of your amplifier. Printed on the template
are instructions for flush or semi-embedded mounting, or for installing it on a flat surface. If you
want to hide the cables, you can refer to the proper holes on the template.
You can connect the cables to ECI-H module
before securing it to the amplifier.
Choose the module position and follow
the connection instructions you can find on
the labels. The amplifier must be off.
I
Mounting template
I
How to run the cables under the amplifier
If you use CONNECTION Audison interconnects, attach Y BLOCK on one of the mounting pins of
the amplifier after plugging in RCA connectors.
Route the cable in the proper location and secure it with the supplied clips.
To attach the clip, insert the tongue first, and then press until you hear a click.
I
Flush mounting
I
Semi-embedded mounting
