The Universal Sound
LRx 3.1MT
LRx 5.1MT
Owner’s manual
I
LRx 3.1MT When mounting ECI in reverse
A label is placed under the amplifier, near the input module, indicating the correct connections and
configurations.
I
LRx 5.1MT When mounting ECI in reverse
A label is placed under the amplifier, near the input module, indicating the correct connections and
configurations.
Power supply/Outputs/Other functions Panel
The panel with the power supply and speaker terminals is protected by a removable cover and
end plate.
I
How to remove the cover
I
How to reassemble the cover
