Audison SR 4 - Amplifier Output Configurations; 4-Channel Output Wiring Modes

POWER OUTPUTS
MID-HIGH
LEFT
MID-HIGH
RIGHT
WOOFER
LEFT
WOOFER
RIGHT
MIN
2 Ω
MIN
2 Ω
4CH MULTICHANNEL
4 Channels Mode
MAX: 8 AWG
10 mm
POWER OUTPUTS
MID-HIGH
LEFT
MID-HIGH
RIGHT
WOOFER
LEFT
WOOFER
RIGHT
OR
MIN
2 Ω
MIN
2 Ω
4 Channels Mode
FRONT
LEFT
FRONT
RIGHT
REAR
LEFT
REAR
RIGHT
MIN
2 Ω
MIN
2 Ω
4CH FRONT - REAR
7
