6. Specifications
RF Input Connector X1
RF Output Connector X1
Frequency Range
Signal Level
Transport Stream
Profile Level
Video Profile and Level
Input Rate
Video Output Connectors
USB Port
Power Input
Standby Power Consumption
Power Consumption
USB Maximum Load
Video Format
Audio Format
Video Output
D-Type, IEC-169-2, Female
D-Type , IEC -169-2, Male (Loopthrough)
174MHz ~ 230MHz (VHF) and
470MHz to 862MHz (UHF)
-10 dBm to -70 dBm
MPEG-2 ISO/IEC 13818-1
MPEG-1 MPEG-2 MP@ML
MPEG-4 AVC/H.264 HP@L3/H.264/AVC HD
Max. 80Mbit/s @ MPEG2
Max. 60Mbit/s @ H.264/AVC
HDMI, SCART
USB 2.0
AC 220-240V 50-60Hz
Maximum 0.5W
Maximum 6W
DC 5V 500mA
4:3/16:9 Switchable
MPEG Layer I & II 32/44.1/48KHz
CVBS RGB
Dimensions
Music
Movie
Net Weight
232g
150 x 108 x 35 mm
mp3,wma, ogg
jpg, jpeg, bmp
mpg, mpeg, dat, ts, trp, tp, m2ts, vob, mp4, mov,
mkv, divx, avi, 3gp
Media Formats
Problems
Problems listed below do not necessarily signify a fault with the unit. Please check this list
before requesting repairs.
7. Troubleshooting
No Power
Plug the power cord into the outlet tightly and turn on the
device.
Check che connection to tthe monitor.
Check the video output, TV format in Display menu.
Cancel Mute. Press MUTE button.
Increase volume. Prss VOL+ buton
Check the connection to the target audio device.
Restore the factory default, then try again.
Possible Causes and Solutions
Picture freezing, and/or
sound distorting
Signal too weak, please check the aerial. Try to use a
proper roof top aerial or an amplified aerial.
No signal
Signal too weak, please check the aerial. Try to use a
proper roof top aerial or an amplified aerial.
Change the batteries.
Operate within normal range. (max 5 meters, 30°)
The sensor is pointed to by bright light
Remote control does not work
Motors/Trains/High Voltage Lines and Neon Lights may
affect the signal.
Snowstorm
No recording
No USB memory is connected.
No free space on the storage.
No sound
No image
This operation instruction is only intended for reference. No further notice is available to
any modification of all information contained therein. Due to continuing improvements,
the features and design are subject to change without notice.
Warning
No user serviceable components are fitted inside this Receiver. Do not attempt any repairs,
as this will invalidate the warranty. Any repairs must be carried out by either the
manufacturer or their nominated service centre. Parts inside this set are subject to high
voltage.
