12. Technical data
Information The following technical data includes standard and optional features. For detailed
information on the customer-specific version, refer to the order-relevant data sheet.
This data sheet can be downloaded from the Internet at http://www.auma.com in
German and English (indication of commission number required).
12.1. Features and functions of actuator
Standard:
●
SQ: Short-time duty S2 - 15 min
●
SQR: Intermittent duty S4 - 25 %
Options:
●
SQ: Short-time duty S2 - 30 min
●
SQR: Intermittent duty S4 - 50 %
●
SQR: Intermittent duty S5 - 25 %
Type of duty
1)
Refer to actuator name plateTorque range
Refer to actuator name plateOperating time for 90°
Standard: 3-ph AC asynchronous motor, type IM B9 according to IEC/EN 60034 Part 1Motor
Refer to motor name plate
Permissible variation of mains voltage: ±10 %
Permissible variation of mains frequency: ±5 %
Motor voltage and frequency
Standard: F, tropicalized
Option: H, tropicalized
Insulation class
Standard: Thermoswitches (NC)
Option: PTC thermistors (according to DIN 44082)
Motor protection
Voltages: 110 – 120 V AC, 220 – 240 V AC or 400 V AC (externally supplied)
Power depending on the size 12.5 – 25 W
Motor heater (option)
Standard: Adjustable between 75° and < 105°
Options: 15° to < 45°, 45° to < 75°, 105° to < 135°
Swing angle
Self-locking
Part-turn actuators are self-locking, if the valve position cannot be changed from standstill
while torque acts upon the output drive.
Self-locking
Manual drive for setting and emergency operation, handwheel does not rotate during elec-
trical operation.
Option: Handwheel lockable
Manual operation
Indication whether manual operation is active/not active via switch (1 change-over contact)Indication for manual operation
(option)
AUMA plug/socket connector with screw-type connectionConnection to controls
Standard: Coupling without bore
Options: Machined coupling with bore and keyway, square bore or bore with two-flats accord-
ing to EN ISO 5211
Coupling
Dimensions according to EN ISO 5211Valve attachment
Electronic control unit
Magnetic limit and torque transmitter MWG for 1 to 500 turns per stroke or 10 to 5,000 turns
per stroke
Limit switching
Via MWG (like limit switching)Torque switching
Via MWGPosition feedback signal, ana-
logue (option)
Via MWGTorque feedback signal, ana-
logue (option)
Continuous indication, adjustable indicator disc with symbols OPEN and CLOSEDMechanical position indicator
Standard: Resistance type heater, 5 W, 24 V AC, (internal supply)Heater in switch compartment
Temperature sensor PT 100Temperature for motor (option)
Temperature sensor PT 100Temperature for gear housing
(option)
57
