23
On/Standby 1 10 EQ
OK 2 11 Mute
Arrow keys for navigating through menus or lists 3 12 VOL+/VOL- (change the volume)
MODE
Choose between FM, DAB, internet radio, AUX,
BT, network media player
4 13
FAV
Go to favourites / stored presets
MENU 5 14
6 15
SLEEP/SNOOZE 7 16 SHUFFLE/REPEAT
8 17 INFO
Num pad 9
Use your thumb to press the lid of the battery compartment and pull it out. Install a CR2025 type 3V battery into the
battery compartment, taking care to insert it with the positive (+) side up.
Caution: Risk of explosion of battery if replaced by an incorrect type.
Getting Started
The items enclosed in the packaging box are as follows:
• Unit
• Power adaptor
• Audio cable with 3.5mm jack at both ends
• User manual
Connect the power adaptor to the back of the unit and plug it into power socket.
Get the network environment ready
• For wired LAN
Use an Ethernet cable (RJ45 jack) to connect the LAN ports on the unit and your network device.Check if the light indi-
cators on the network device are in appropriatestatus.
• For WIFI
Make sure you have setup the wireless network and you have the WEP, WPA or WPA2 security password to activate
the connection.
You may also use the WPS (WiFi Protected Setup) function for easy pairing between the network device and the unit.
Check if the light indicators on the network device are in appropriate status.
At initial use, the system asks whether you want to start the Setup Wi-
zard. Select YES to continue the setup. Details of the Setup Wizard will
be explained below. After choosing NO, the next screen asks if you
would like to run the wizard next time unit is started.
The unit will automatically connect to the network that was set the last
time you had the radio powered on. In case you want to change the net-
work, enter System Setting to congure the corresponding connection.
