ANTENNA INSTALLATION
1 USB Port
2 Earphone Jack
3 ENTER/NAVIGATE Swivel Knob
4 MEMORY Button
5 MODE Button
6 BACK Button
7 MENU Button
8 Display
9 Play/Pause Button
10 Fast Backward Button
11 Fast Forward Button
12 INFO Button
13 Standby/VOLUME Button
14 Remote Control Sensor
MEMORY MENU
MODE BACK
ENTER
NAVIGATE
INFO
VOLUME
USB
1 2 3 4 5 6 7 8 9 10 1112 13 14
W-LAN
ANALOG
ANALOG
INPUT
OUTPUT
AUDIO
AUDIO
ANALOG
R
L
OUTPUT
AUDIO
OPTICAL
DIGITAL
COAXIAL
OUTPUT
LAN
INPUT
DC IN
ANTENNA
15 16 17 18 19 20 21 22 23 24
15 DC IN Jack
16 W-LAN Antenna Installation Hole
17 AUDIO OUTPUT ANALOG R/L Jack
18 ANALOG AUDIO INPUT Jack
19 ANALOG AUDIO OUTPUT Jack
20 AUDIO OUTPUT DIGITAL OPTICAL Jack
21 AUDIO OUTPUT DIGITAL COAXIAL Jack
22 LAN INPUT Jack
23 Antenna Installation Hole
24 Antenna Holder
