26
EN
1 Bracket mounting slot (for slide unit into under kitchen bracket)
2 FM wire antenna
3 DC INPUT socket (for DC 5V 2A Power Input)
4 Button (Power ON / OFF)
5 / ST Button (Clock Set / FM Stereo On/O)
6 PRE / MEM Button (Preset Station / Memory Station)
7 LIGHT Button (Light On/O)
8 RESET/MODE Button (FM / BT, Reset)
9 LED Anzeige
10 TUN -/ button
11 TUN / button
12
/ST / /AMS button
(Play/Pause, Pick up/Hang up call/Last dialed, Auto Memory Stations)
13 ALARM button (Set for Alarm 1/2)
14 TIMER button (Set for Clocking Timer
15 MIC microphone (for hand-free)
16 Adjustment button (+ / -, Enter/Snooze)
17 LED light bar (white LED x 9)
18 Left loud speaker
19 Left bass radiator
20 Right bass radiator
21 Right loud speaker
