AUDIO
Setting the low and high pass filters (LPF and HPF). The settings of this menu item
will be different for configurations 2-WAY / 3-WAY!
X-OVER
Front HPF - HPF setting for the front speakers
F-HPF FRQ - cutoff frequency: TROUGH (off) / 30 / 40 / 50 / 60 / 70 / 80 / 90 / 100 /
120 / 150 / 180 / 220 / 250 / 315 / 400 / 500 / 630 / 700 / 800 Hz.
F-HPF SLOPE - steepness of the decline: 6 / 12 / 18 / 24 dB per octave.
F-HPF GAIN - volume level, from -8 dB to 0 dB.
Rear HPF - HPF setting for the rear speakers
R-HPF FRQ - Cutoff frequency: TROUGH (off) / 30 / 40 / 50 / 60 /70 / 80 / 90 / 100 /
120 / 150 / 180 / 220 / 250 / 315 / 400 / 500 / 630 / 700 / 800 Hz.
R-HPF SLOPE - the slope of the decline: 6 / 12 / 18 / 24 dB per octave.
R-HPF GAIN - volume level, from -8 dB to 0 dB.
Subwoofer LPF - low-pass filter (LPF) and subwoofer phase adjustment.
SW LPF FRQ - Cutoff frequency: 30 / 40 / 50 / 60 / 70 / 80 / 90 / 100 /
120 / 150 / 180 / 220 / 250 / 315 / 400 / 500 / 630 / 700 / 800 Hz /TROUGH (off).
SW LPF PHASE - electrical phase switching: 0° /180°
SW LPF GAIN - volume level, from -8 dB to 0 dB.
SW LPF SLOPE - steepness of the decline: 6 / 12 / 18 / 24 dB per octave.
2-WAY (Regular)
Tweeter - treble setting
FRQ - frequency selection: 1 / 1.6 / 2.5 / 3.15 / 4 / 5 / 6.3 / 8 / 10 / 12.5 kHz.
GAIN LEFT - volume level (left channel), from -8 to 0 dB.
GAIN RIGHT - volume level (right channel), from -8 to 0 dB.
8
