C300H / C300HI / C300H x4 / C300HI x4
C350H / C350HI / C350H x4 / C350HI x4
109
Oil level on front axle (fig. 1)
This should be checked while the forklift is on flat ground. The oil of the differentials and
the reducers is connected internally.
Differential: Checking the level
- To check the oil level in the differentials use the cap (b).
Differential: Draining
- To drain the oil, unscrew the plug (c) located on the lower part.
Dispose of used oil in authorized centres.
Differential: Topping up
- Fill with the specified oil through the opening of the plug (b). See the FLUIDS
AND LUBRICANTS CHART (references and capacities) in this Operator’s
manual for oil specs and capacity.
(fig. 1)
b
a
Periodic
Maintenance
Operations
