Autel MaxiProgrammer XP400 Pro - 3 Support Chip Coverage; Register Coverage

9
No.
Color
Definition
Note
17
White
OSC
Shielded
Twisted
Table 2-5 Definitions of MC9S12 Cable
No.
Color
Definition
Note
1
Red
+5V
2
Black
GND
3
Green
XCLKS
4
Blue
T/R
5
Yellow
RESET
6
Black
GND
Shielded
Twisted
7
White
OSC
Shielded
Twisted
Cross-shaped Signal Pin
The Cross-shaped signal pin is used to place MCU spare cable or DIY
signal cable to read or write MCU and ECU chips.
Vehicle Key Slot
Holds the vehicle key to read or write vehicle key information.
Transponder Slot
Holds the transponder to read or write transponder information.
Mercedes Infrared Slot
