Autel MaxiProgrammer XP400 Pro - Components and Ports; USB Port; DC Port; DB 26-Pin Port

6
Description
APA108 – MCU Cable
APA109 – MC9S12 Cable
NOTE
Optional Accessories can be purchased separately.
Components and Ports
Figure 2-1 XP400 Pro Views
1. USB Port – Provides data communication and 5V DC power supply.
2. DC Port – Provides 12V DC power supply.
3. DB 26-Pin Port – connects with the Mercedes Benz infrared
collector, ECU cable, MCU cable and MC9S12 cable.
