Wiring Installation Instructions for : Pressure Gauge
2 1/16” Spek Pro Fuel Rail Pressure Gauge
SPEK PRO™ FUEL RAIL PRESSURE GAUGE
FEATURES:
SPEK PERFORMANCE GAUGE FEATURES:
• INTELLIGENT ELECTRICAL GAUGES.
• GAUGES ARE PROGRAMMED THROUGH COMMAND KEYS ON FACEPLATE.
• STEPPER MOTOR DRIVES THE GAUGE POINTER OVER A 280 DEGREE SWEEP.
• WIDE-ANGLE-DIAL™ HAS A 15% LARGER VIEWING AREA ON A 2 1/16” GAUGE.
• PROGRAMMABLE 7 COLOR DIAL AND RED POINTER ILLUMINATION.
• OPTIONAL OUTPUT CONTROL MODULE.
INSTALLATION INSTRUCTIONS:
1 DISCONNECT NEGATIVE (-) BATTERY TERMINAL.
2 VARIOUS MOUNTING SOLUTIONS ARE PRESENTED BY PROPARTS
DASH INSTALLATION: SELECT LOCATION IN THE DASH TO MOUNT GAUGE AND CUT A 2 1/16” HOLE.
USE A FILE TO INCREASE THE HOLE SIZE IF REQUIRED. BE SURE THERE IS SUFFICIENT ROOM
BEHIND THE HOLE FOR THE METER CASE AND THE CONNECTORS YOU WILL USE.
3 IF A SUITABLE HOLE IN THE FIRE WALL IS NOT AVAILABLE, CUT AN 11/16 HOLE.
4 GROMMET MUST BE CUT TO PERMIT INSTALLATION OF WIRIN
G HARNESS. (SEE DIAGRAM 1)
7
PACKAGE CONTAINS:
• Pressure Gauge
• Pressure Sender
• Wiring Harness
• Mounting Cup
• ( 1 ) N e o p r e n e E D P M G r o m m e t
To Next Page
