WIRE CONNECTION STEP
1. Connect the red wire to the reverse light(positive).
2. Open the inner plastic panel and remove it from the hatch or tailgate.(The panels are usually attached to the tailgate by clips. It may take a
bit longer to avoid clip damages. Once the panel is removed, the work will be done easily)
3. Carefully peel the skin of the red wire, then find the reverse light power wires and fix the red wire of the video cable with the positive of
reverse wire.
4. Connect the 5 pin camera wire to the video cable.
