COMPONENTS SUPPLIED
Description Ref. Q.ty IMAGE / TASK
Roof air conditioner (complete unit) A 1
Cilyndrical head screw M6x20 AA 10
For fastening the cover
Spring washer Ø6 BB 10
Plain washer Ø6xØ12 CC 8
Rubber washer Ø6xØ13.5 DD 8
Plain washer Ø6xØ18 EE 2
Rubber washer Ø6xØ18 FF 2
Gasket (length 1.85 m) B 1
Hexagonal head screw M8x55 GG 6
For fastening the air conditionerPlain washer Ø8xØ17 HH 12
Self-locking nut M8 II 6
Rubber spacer Ø44 C 6
Air di󰀨user D 1
Self-tapping screw Ø5x22 JJ 6
For fastening the air di󰀨user
Plain washer Ø5xØ15 KK 6
Electronic control unit (cooling / heating version) E 1
Ventilation speed selector + Threaded ring for selector (only
cooling version)
F 1 + 1
