MultiGrow Installation Guide
V2.0 MultiGrow Installation Guide Copyright© 2018 Autogrow Systems Ltd 13
EpMT Remote Sensors Module
The EpMT Module stands for EC, pH, Moisture & Temperature. This is
an input Module for the following devices:
• EC probe
• pH electrode
• Moisture sensor
• Temperature probe
• Water meter
• Pluviometer or pressure switch
The EpMT Module is used primarily for fertigation, dosing and root zone / run-off monitoring.
The diagram below shows the connections on the EpMT Remote Sensors Module, wiring diagrams
are also available in the Appendix.
Notes:
The pH electrode connects directly to the BNC connector. Note that to
facilitate easy probe changes in the future, the cable gland used for the
pH cable should not carry any other wires.
If using a GS3 Moisture probe as apposed to an EC5 then the GS3 dip
switch must be selected on the EpMT Module PCB board.
