AUTOHELM Bidata ST30 - Spare Parts List

ST30 Bidata Instrument
ST30 Bidata Service Manual 83009-2 5
Z171
2.1 Spare Parts List
ST30 Bidata display unit
The item numbers refer to Figure 1: ST30 Bidata display unit.
Item Spare Description Part No. Comments
Rear case assembly, including W005
2 Rear case
3 Sealing gasket Affixed to rear case
4 Labels (selection) Fit appropriate label
3 Sealing gasket Q084 Pack of 5
3 Sealing gasket W043 Pack of 10
5 Case seal Q080 Pack of 5
PCB assembly, including Q077
6 PCB
7 Foam reflector Also part of Q078
8 Diffuser Also part of Q078
Digital LCD kit, including Q078
7 Foam reflector Also part of Q077
8 Diffuser Also part of Q077
9 Elastomer
10 LCD
11 LCD surround
12 Locking wedge (x5)
13 Facia W008 Keypads bonded to facia
Female spade connector kit Q085 Not illustrated
