Automated Logic U551 User Manual

Revised 8/14/02 • U551 3 © 2002 Automated Logic Corporation
Job Start-Up
WebCTRL and SuperVision require different
module drivers and Eikon software. The
appropriate module drivers, Eikon for
WebCTRL or Eikon 3.0a or later, and a sample
U-Line GFB can be downloaded from
Automated Logic Corporation’s web site
(http://www.automatedlogic.com). You can
also order a copy of Eikon for WebCTRL or
Eikon on CD through Order Administration.
Job Start-Up for WebCTRL
For a WebCTRL system, you need these items
to properly start up and support U-cards:
• UNI/16 with the DRV_UNI16 module
driver, or UNI/32 with the DRV_UNI32
module driver
• Eikon for WebCTRL
• U-Line Zone GFBs
Job Start-Up for SuperVision
For a SuperVision system, you need these
items to properly start up and support U-
cards:
• UNI/16 with the U1M module driver,
UNI/30 with the U3M module driver,
UNI/32 with the UNM module driver, or
UNI/59 with the U5M module driver
• Eikon 3.0a or later
Figure 1. U551 Layout and Dimensions
OnesTens
Gnd
Temp
Sw
LS5v
LogiStat
Tx
Enclosed Energy
88FO
E143900
TYPE: 000553
Management Equipment
R
Run
n/c
Gnd
AO-1
DO-5
DO-4
DO-3
DO-2
DO-1
BUSS
Power for D.O.s
Gnd
IN-3
Gnd
IN-2
Gnd
IN-1
Error
Flow 1
+10V
Gnd
Flow 2
Rx
Flow Sensor
MS/TP
BACnet
TM
CAUTION:
On Off
U551
Gnd
24 Vac
Unet +
Unet -
U-com
5
6
8
9
0
7
23
41
5
6
8
9
0
7
23
41
0.2"
0.5 cm
5.7"
14.5 cm
5.2"
13.2 cm
0.2"
0.5 cm
2.6"
6.6 cm
5.1"
13 cm
Outputs
24V Max, 1A Max
This product was designed to be
mounted inside the building envelope.
Warranty voided if mounted outside.
Analog
Inputs
5V Max
0-10 Vdc
5mA Max
Analog
Output
Class 2
24 Vac
50-60 Hz
12VA
0.5A
Use Copper
Conductors
Only
