Automated Logic ZS Series User Manual

Appendix: Rnet tag numbers
This Rnet tag number...
Indicates this type of value...
001
Zone Temp
002
Zone Humidity
003
Zone CO2
004
Zone VOC
100
Fan Status
101
Fan Command
102
Cool Stage 1
103
Cool Stage 2
104
Cool Stage 3
105
Cool Stage 4
106
Heat Stage 1
107
Heat Stage 2
108
Heat Stage 3
109
Heat Stage 4
110
Hot Gas Bypass
111
Reheat
112
Reversing Valve
113
Enthalpy Wheel Status
114
Dehum Wheel Status
116
Energy Save Mode
117
Occupied Status
121
Override Status
300
Outside Air Temp
301
Outside Air Humidity
302
Outside Air CO2
303
Mixed Air Temp
304
Supply Air Temp
305
Return Air Temp
306
Effective Cooling Setpoint
307
Effective Heating Setpoint
308
Air Flow
309
Primary Damper Position
310
Cooling Stage
311
Heating Stage
312
Cooling Valve
313
Heating Valve
314
Reheat
315
Secondary Damper Position
316
Supply Air Humidity
317
Return Air Humidity
318
Entering Water Temp
319
Leaving Water Temp
320
Supply Air Static Pressure
ZS Sensors ALC Proprietary and Confidential © 2015 Automated Logic Corporation
Rev. 4/27/2015 All rights reserved
9
