Automatic Systems SlimLane 9 Series User Manual

p. 46 / 98
SL 9xx-MT-EN
1. Support profile for DIRAS cells
2. Transmitter cells
3. Receiver cells
4. Fixing bracket
5. M4 washer
6. M4 x 10 screw
7. Filter screen for receiver cells
8. Beam guide for receiver cells
! Mounting instruction: hole marked x in front of cell marked x
9. Polycarbonate screen
10. M3 x 10 screw
11. Polycarbonate screen support for receiver cells
12. M3 x 8 screws
13. Polycarbonate screen support for transmitter cells
14. Clamp
15. Attach for cable shield
! Tighten CAN cable shield into attach
16. M4 stainless steel washer
17. M4 x 16 screw
