SL 9xx-MT-EN
8.
8.1.
8.1.1.
AS1190
Control board based on
ARM9 technology
RS232/485
Ethernet
USB 2.0 host
USB device
AS1168
Input/Output
AS1185
Left Motor Drive
AS1185
Right Motor Drive
AS1142
Emitter DIRAS #3
AS1142
Emitter DIRAS #2
AS1142
Emitter DIRAS #1
AS1142
Emitter DIRAS #0
AS1143
Receiver DIRAS #3
AS1143
Receiver DIRAS #2
AS1143
Receiver DIRAS #1
AS1143
Receiver DIRAS #0
Digital Input
Digital Output
Buzzer
Buzzer Status
AS1170
Motor Drive
Locking in case of power leakage
Brake
Orientation pictogram
AS1170
Motor Drive
Locking in case of power leakage
Brake
Orientation pictogram
Motor
Motor
Open CAN
