WARNING:
THE OPENER
MUST
SECURELY
FASTENED
TO
A STRUCTURAL
SUPNRT
OF
THE GARAGE.
FAILT]RE
FASTEN
THE OPERATOR
CORRECTLY
I4/ILL
LEAD
TO POSSIBLE
OPERATOR
FAILURE
CAUSING
SERIOUS
INJARY
TO PERSONS/AND
OR PROPERTY.
STEP
9
Determine
the centre
of
the door and
mark this
location on
the
wall above
and on top of
the
door.
Then draw
two
(2)
lines 2l.5mm on each
side of
the door.
(Fig.
9)
STEP
10
Raise the door
to open
position. Reset the
operator
on
the top
edge of the door
with end
of
the track
against
the
header
and
drive
unit
support
in
level with the
lowest
point
of the
open door.
(Fig.
l0)
Note:
do
not
slide
operator
track on
face
of
the
door
when
it is
open.
Attach the angle
(not
supplied)
to the
ceiling
and
connect angle
and drive
unit with
two
(2)
flat
perforated
strips of
the angle
(not
supplied)
with
M8
x 20mm screws
and
nuts. Strips
should
not
extended
more than
18mm below
centre
of the
mounting
holes
of
the drive
unit.
Do not
lock
screws
atthis stage.
(Fig.
10a)
Warning:
Refer
to warning
as step
8.
STEP
11
Close
Door
slowly
The
operator
track
will be
elevated
by the
top edge of
the door as
it
moves. Stop the door
when
it is at
its highest
point
of travel.
(Fig.
11)
Allow
25mm additional
height for clearance
between
the door
and the
track. Support
track
in this
position
and the close
the door.
(Fig 11a) Top
of
door
must not touch
tube.
FIG.10
,
qnnrum
Page
7
