1.
LIGHT
CODE
button
(White)
is
used
for
storing
or erasing
the
transmitter
button
(code)
you
wish
to
use
to tum
the courtesy light
on
the
Opener on
and off.
2.
DOOR
CODE
button
(Blue)
is
used for
storing
or
erasing
the
transmitter
button
(code)
you
wish
to use to
command
the door'to
open
,
stop or
close.
3.
CLOSE DRIYE
button
(Red)
is
ur-
,
during
installation
to help
set
thEilose
tiirlt
stop
position.
Pressrng
and
holding
this
button
will move
the
door in
the
close
direction
Movement
stops
when
the button
is
released.
NOTE:
The
close
safety
obstruction
detection is
inoperable
wheneyer
the
Close
I)rive
button
is
used
to move door.
4.
CLOSE LIMIT
Led
(Red)
.the
led
is
very helpful
during installation,
it illuminates
and flashes
when
the
door is
closing
and remains
steady
on
when
the close limit
is
activated
5.
IUTO
CLOSE
button
(White)
is
usbto
adjust
the
auto
close
time.
While
holding
in
the Auto
Close
button
and then
pressing
(each
press
will
increase
the time
by 5
seconds)
the
Open
button
the
time is
increased,
pressing
the
Close
button
will
decrease
the
time.
6.
RESET
button
is
used
to
initialise
and
set the
door/opener
operating parameters,
including
cycle
times
and obstruction
force
set-
tings.
Check
the installation
manual
for
other
uses.
7.
O I S
/ C
button
(Yellow)
is
used
during
installation
to test
the
open,
stop
and
close
cycles for
the Opener.
The
Opener has
to be
initialised
by
the Reset
button
before
the O/S/C
but-
ton
becomes
operable.
8.
CLOSE LIMIT
ADJUST
SCREW
(Red)
is
used
to
fine
ad-
just
the close limit
stop
position.
Check
installation
section
on how
to
adjust.
9.
OPEN LIMIT
ADJUST
SCREW
(Green)
is
used
to
fine
adjust
the
open limit
stop
position.
Check
installation
section
on
how
to
adjust.
10.
CLOSE LIMIT
CAM
(Red)
is
used
to set
the
close limit
stop
position.
Check installation
section
on
how
to adjust.
11.
OPEN Drive
button
(Green)
is
used
during installation
to help
set
the
open limit
stop
position.
Pressing
and holding
this
bufion
wi_ll move
the
door in
the
open
direction.
Movement
stops
when
the
button is released.
NOTE:
The
open
obstruction
detection is
disabled
whenever
the
Open Drive
button is
used
to
move
door.
12.
OPEN
LIMIT
Led
(Green)
the
led
is
very
helpful
during
installation,
it illuminates
and
flashes
when
the
door is
opening
and
remains
steady
on when
the
open
limit
is
activated
13.
OPEN
LIMIT
CAM
(Green)
is
used
to set
the
open limit
stop
position.
Check installation
section
on how
to adjust.
14.
FORCE
MARGIN
SET
button
is
used
to
change
the force
pressure
when
the'door
encounters
an
obstruction.
Pressing
the Force
Margin
Set button
and
Open
or
Close
button
will
increase
or
decrease
the force.
Normally
the
force pressure
is
set automatically.
The
Force
Margin
Set is
only
ever
used if
other
environmental
factors
(wind,
etc.)
effect
the operations
of
the Door/Opener.
15.
P.E.
Input is
for
connection
of
Electric
Beams
(optional
extra)
for
extra
safety
obstruction
protection.
NOTE:
P.E.
SHUNT
must not
be
removed
dherwise
the Opener
will
not
function
correctly.
Remove
only
when
a
P.E.
is
to be
connected
16.
EXTERNAL
RECETVER
INPUT
is
the
input
where
an
extemal receiver
can
be connected.
The
receiver
must
be able
to
operate
of 24
vohs DC.
17.
SECURALIGIIT
Input
is
used
for
connecting
a
Securalight
(optional
extra)
Monitor.
A
Securalight
is
a monitor
unit which
is
mounted
inside your
home
and is
connected
to
the
Opener
by wire
cable.
The
monitor
indicates
the
ststus
ofthe
door,
for
example if
the
door is
moving
or
is
opened
or
closed,
etc. An
audible
beeper
sounds
whenever
the
door is
moved
by
the
Opener. The
door
can
also be
controlled
from
the monitor
unit.
18.
O/S
tC
Inputisfor
connecting
the
wired
Wall
Switch.
19.
ENGAGE
/ DISENGAGE
HANDLE
when pulled
down
to-
wards
door
and released
will select
manual
mode
when
there is
a
power
failure.
Pulling
away
from
door
and
releasing
again
will
select
automatic
mode
