AN: NPN output 2
1C: SPDT relay output 2
Counter/Timer/Tachometer
Model Number Explanation
Features
-Can operate as a digital counter, timer, combination timer + counter or tachometer
-Accepts voltage and non-voltage inputs from a wide variety of NPN, PNP, or dry contact sensors
-Selectable counting speeds from 1 to 10,000 cycles per second
-Multiple transistor and relay outputs can operate as momentary or maintained
-Double-line, 6-digit, 2-color LCD display
-Easy configuration with externally accessible DIP switches or the lockable keypad
-Display decimal point selection
- Available in 120-240VAC and 24VDC powered models
-UL508 listed, CE marked
Unpacking
After receiving the CTT Counter/Timer/Tach, please check for the following:
• Make sure that the package includes the CTT Counter/Timer/Tachometer, the mounting bracket and
hardware, and the Quick Start Guide.
• Inspect the unit to insure it was not damaged during shipment.
• Make sure that the part number indicated on the label corresponds with the part number of your order.
