General Description
The CTT series is an extremely versatile multi-function device that is easily configured for operation as a digital
counter, timer, combination timer + counter, or tachometer. Both voltage and non-voltage inputs are accepted
from a wide variety of sensor types with NPN, PNP, or dry contact outputs. The first output on the CTT is
a single-pole, single-throw relay and NPN transistor that operate concurrently. The second CTT output can
be ordered as either a single-pole, double throw relay or NPN transistor. Parameters are easily set using the
externally accessible DIP switches or the lockable keypad. The double-line, 6-digit, two-color LCD display
shows the counter, timer, or tachometer present values, setting values and menu parameters during set-up.
Additional individual indicators are provided for inputs, outputs and functions. The standard 1/16 DIN size,
included panel mounting clip and gasket make panel mounting a snap. The CTT is available in 120-240VAC
and 24VDC powered models.
www.automationdirect.com
1-3
Digital Counter / Timer / Tach User Manual, 1st Ed.
Timer Functions (Up or Down)
Signal On Delay 1 Repeat Cycle
Signal On Delay 2 Repeat Cycle Hold
Signal Off Delay Repeat Cycle 2
Signal On Signal Cumulate
Power On Delay Signal Twin On-Start
Power On Delay Hold Signal Twin Off-Start
Tachometer Output Modes
Select from four (4) different output modes
2Lo/1Lo
2Lo/1Hi
2Hi/1Lo
2Hi/1Hi
Counter Functions Counter Input Modes Counter Output Modes
1-Stage Up
Select from eleven (11) different
output modes (F, N, C, R, K, P, Q,
A, S, T, D)
2-Stage Down
Batch Up / Command Down
Total Up/ Down
Dual Quadrature
Addition
Subtraction
Timer + Counter
Timer Functions (Up or
Down)
Counter Input Modes Counter Output Modes
Signal On Delay 1 Up
Select from eight (8) different out-
put modes (F, N, C, R, K, P, Q, A)
Signal On Delay 2 Down
Signal Off Delay
Signal On
Power On Delay
Power On Delay Hold
Repeat Cycle
Repeat Cycle Hold
Click on the above thumbnail or go to
https://www.automationdirect.com/VID-RL-0001
for a short introductory video for the CTT units.
