C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8 • 61
Clamp No. Signal Name Description
J301/1 GND encoder ground
J301/2 Z- RS422 encoder index track Z-
J301/3 Z+ RS422 encoder index track Z+ / single-ended index track Z
J301/4 B- RS422 encoder track B-
J301/5 B+ RS422 encoder track B+ / single-ended track B
J301/6 A- RS422 encoder track A-
J301/7 A+ RS422 encoder track A+ / single-ended track A
J301/8 SHIELD Camera shield
J400/1 GND_IO I/O ground
J400/2 PWR_IO Power supply voltage of camera isolated outputs (9V-24V DC)
J400/3 HV-OUT1 Isolated output #1 (9V-24V)
J400/4 HV-OUT2 Isolated output #2 (9V-24V)
J400/5 OUT1 Isolated output #1 (5V)
J400/6 OUT2 Isolated output #2 (5V)
J400/7 IN1 Isolated input #1 (5V/24V)
J400/8 IN2 Isolated input #2 (5V/24V)
J500/1 VCC_L Input power supply voltage for laser control
J500/2 VCC_L Input power supply voltage for laser control
J500/3 GND_L Input ground for laser control
J500/4 GND_L Input ground for laser control
J500/5 DO Output for digital modulation of laser (TTL signal)
J500/6 AO Output for analog modulation of laser (0-5V DC)
J500/7 AI Analog Input for monitoring specific functions of laser (0-5V DC)
J500/8 SDA Data line of I²C bus interface
J500/9 SCL Clock line of I²C bus interface
J500/10 SHIELD Camera shield
