D0-06AA General Specifications
External Power Requirements
100–240 VAC/50–60 Hz, 40VA maximum
Communication Port 1 9600 baud (Fixed),
8 data bits, 1 stop bit odd parity
K–Sequence (Slave), DirectNET (Slave), MODBUS (Slave)
Communication Port 2 9600 baud (default)
8 data bits, 1 stop bit odd parity
K–Sequence (Slave),DirectNET (Master/Slave), MODBUS
(Master/Slave), Non-sequence / print, ASCII in/out
Programming cable type
D2–DSCBL
Operating Temperature
32 to 131°F (0 to 55°C)
Storage Temperature
–4 to 158°F (–20 to 70°C)
Relative Humidity
5 to 95% (non-condensing)
Environmental air
No corrosive gases permitted
Vibration
MIL STD 810C 514.2
Shock
MIL STD 810C 516.2
Noise Immunity
NEMA ICS3–304
Terminal Type
Removable
Wire Gauge
One 16 AWG or two 18 AWG, 24 AWG minimum
AC Input Specifications
Input Voltage Range (Min. - Max.)
80–132 VAC, 47–63 Hz
Operating Voltage Range
90–120 VAC, 47–63 Hz
Input Current
8mA @100VAC at 50Hz
10mA @100VAC at 60Hz
Max. Input Current
12mA @132VAC at 50 Hz
15mA @132VAC at 60 Hz
Input Impedance
14Kq @50 Hz, 12Kq @60Hz
ON Current/Voltage
> 6mA @ 75VAC
OFF Current/Voltage
< 2mA @ 20VAC
OFF to ON Response
< 40ms
ON to OFF Response
< 40ms
Status Indicators
Logic Side
Commons
4 channels / common x 5 banks (isolated)
AC Output Specifications
Output Voltage Range (Min. - Max.)
15–264 VAC, 47–63 Hz
Operating Voltage
17–240 VAC, 47–63 Hz
On Voltage Drop
1.5 VAC (>50mA) 4.0 VAC (<50mA)
Max Current
0.5 A / point, 1.5 A / common
Max leakage current
<4mA @ 264VAC
Max inrush current
10A for 10ms
Minimum Load
10mA
OFF to ON Response
1ms
ON to OFF Response
1 ms +1/2 cycle
Status Indicators
Logic Side
Commons
4 channels / common x 4 banks (isolated)
Fuses
None (external recommended)
