TECHNICAL DATA DIM. C15 C15 X
Press tonnage
kN(US tons) 440(48) 440(48)
Motor power
kW 2x5 2x5
Max. bending lenght (D) mm 1600 1600
Distance between side
frames
mm 1550 1550
Frame width (A)
mm
2230 2230
Frame height (B)
mm
2150 2450
Frame depth (C )
mm
1550 1550
Throat depth mm 150 150
Table height mm 820 820
Weight kg
3000 3200
daylight mm 500 650/800
Y-axis stroke mm 250 250
Y-axis repeatin accuracy mm +/-0.002 +/-0.002
Y-axis max working speed mm/s 10 (20*) 10 (20*)
Y-axis approach speed mm/s 100 100
Y-axis return speed mm/s 100 100
X-axis speed mm/s 500 500
X-axis accuracy mm +/-0.025 +/-0.025
X-axis stroke mm 600 600
X-axis max position
dimension
mm 750 750
Delta X-axis speed mm/s 100 100
Delta X-axis accuracy mm +/-0.025 +/-0.025
Delta X-axis stroke mm +/-50 +/-50
R-axis speed mm/s 100 100
R-axis accuracy mm +/-0.05 +/-0.05
R-axis stroke mm 200 200
Z-axis speed
mm/s 1000 1000
Z-axis accuracy
mm +/-0.5 +/-0.5
Z-axis stroke
mm 120 to 1480 120 to 1480
*can be up to 20mm/s, depending on requlations.
