TECHNICAL DATA DIM. G20 G25
Press tonnage
kN(US tons) 600(67) 800(89)
Motor power
kW 3x5 4x5
Max. bending lenght (D) mm 2040 2550
Distance between side
frames
mm 2200 2700
Frame width (A)
mm
2990 3500
Frame height (B)
mm
2500 2650
Frame depth (C )
mm
1780 1780
Throat depth mm O-frame O-frame
Table height mm 900 900
Weight kg
5100
6500
daylight mm 600 600
Y-axis stroke mm 280 280
Y-axis repeatin accuracy mm +/-0.002 +/-0.002
Y-axis max working speed mm/s 10 (20*) 10 (20*)
Y-axis approach speed mm/s 100 100
Y-axis return speed mm/s 100 100
X-axis speed mm/s 500 500
X-axis accuracy mm +/-0.025 +/-0.025
X-axis stroke mm 600 600
X-axis max position
dimension
mm 750 750
Delta X-axis speed mm/s 100 100
Delta X-axis accuracy mm +/-0.025 +/-0.025
Delta X-axis stroke mm +/-50 +/-50
R-axis speed mm/s 100 100
R-axis accuracy mm +/-0.05 +/-0.05
R-axis stroke mm 200 200
Z-axis speed
mm/s 1500 1500
Z-axis accuracy
mm +/-0.5 +/-0.5
Z-axis stroke
mm 100 to 1940 100 to 2450
*can be up to 20mm/s, depending on requlations.
