TECHNICAL DATA DIM. G30 G40
Press tonnage
kN(US tons) 1000(111) 1500(166)
Motor power
kW 5x5 6x5
Max. bending lenght (D) mm 3060 4080
Distance between side frames mm 3200 4200
Frame width (A)
mm
4010 5030
Frame height (B)
mm
2830 2950
Frame depth (C )
mm
1780 1780
Throat depth mm O-frame O-frame
Table height mm 900
900
Weight kg 7500
10000
daylight mm 600 600
Y-axis stroke mm 280 280
Y-axis repeatin accuracy mm +/-0.002 +/-0.002
Y-axis max working speed mm/s 10 (20*) 10 (20*)
Y-axis approach speed mm/s 100 80
Y-axis return speed mm/s 100 80
X-axis speed mm/s 500 500
X-axis accuracy mm +/-0.025 +/-0.025
X-axis stroke mm 600 600
X-axis max position dimension mm 750 750
Delta X-axis speed mm/s 100 100
Delta X-axis accuracy mm +/-0.025 +/-0.025
Delta X-axis stroke mm +/-50 +/-50
R-axis speed mm/s 100 100
R-axis accuracy mm +/-0.05 +/-0.05
R-axis stroke mm 200 200
Z-axis speed
mm/s 2500 2500
Z-axis accuracy
mm +/-0.5 +/-0.5
Z-axis stroke
mm 100 to 2960 100 to 3980
*can be up to 20mm/s, depending on requlations.
